Technical Features
| Feeding Speed (m/min) | 15-23 |
| Tape Thickness (mm) | 0.4-3 |
| Panel thickness(mm) | 9-60 |
| Panel Lenght (mm) | ≥120 |
| Panel Lenght (mm) | ≥60 |
| Min. Panel Lenght (mm) | 120*90 |
| Total power (kW) | 19,05 |
| Overall Dimension(L)(W)(H)(mm) | 6000L*830W*1700H |
| Number of the dust hoses and diameters | Ø100*2+Ø125*2 |
Machine Video
General Features
Pre-Milling Unit
"The units are attached to the machine body. The first motor operates in the opposite direction of the feeding direction. The second motor operates in the opposite direction of the feeding direction. The second motor operates in the feeding direction. Both motors have a pneumatic jumping system. Milling up to 40 mm is available (60 mm optional).
Milling rotation speed: 9.000 rpm
Motor power: 2 x 3.7 kW
Blade height: 45 mm
Pre-Heated Lamp
When the pre-heating is use, the result of the sticking of the tape is stronger, specially in cold weathers. The edge of the panel that will be glueing is heated by IR-Lamps
Automatic Pallet Lubrication
Chain is lubricated automatically
